DP090S-14W



Product
information

Product number: DP090S - 14W
Track System:  220-240V~
Dimming: On/Off,TRIAC,1-10V,DALI
Light source: COB LED
luminaire Lifetime: 50.000h(L80B50, Ta25°C)
IP Rating:  54
Working Temperature (°C) -5 ~ +30
Material:  Aluminium
Fitting Colors:  Sandy White / Sandy Black

Packaging
information

N.W. lamp (Kg): 0.44
G.W. Carton (Kg): 11.6
Master carton dimensions(mm): 465x295x288
Quantity per carton: 24

System
overview

Beam Watt CRI Luminous CCT Code
18
14W 90 1148 lm 4000K DP090S-14G40-S01
1115 lm 3000K DP090S-14G30-S01
1059 lm 2700K DP090S-14G27-S01
24
14W 90 1224 lm 4000K DP090S-14G40-M01
1189 lm 3000K DP090S-14G30-M01
1129 lm 2700K DP090S-14G27-M01
38
14W 90 1218 lm 4000K DP090S-14G40-F01
1183 lm 3000K DP090S-14G30-F01
1123 lm 2700K DP090S-14G27-F01
56
14W 90 1289 lm 4000K DP090S1-14G40-WF0
1252 lm 3000K DP090S-14G30-WF01
1189 lm 2700K DP090S-14G27-WF01

Size

DP090S - 14W

Illuminance

DP090S - 14W
